Oiled Screw Pump Units

Weclearmed independently designs, produces and develops high-quality medical air units, good power air units, oil-free scroll pump units, oiled screw pump units, oil-free piston pump units and so on. Large, medium and small flow models can be customized.They have two-year warranty and more than ten years design life!

Send Inquiry

Product Description

Oiled Screw Pump Units specification table-PD

Model number	Connection method	Motor output power Kw/HP	Power	Noise db(A)	Control method	Rated pressure Mpa	Gas productio n volume m3/min	Air outlet connecti on	External Dimension (Lengthwidthheight) mm	Gross weight(kg)
MA-PD-2.2	Belt frequency machine (PD)	2.2/3	3N~380V 50Hz	63	Pressure sensitive	0.8	0.24	0.24	800560900	0.24
MA-PD-3.7-A		3.7/5		63			0.4	G1/2	680640960	134
MA-PD-7.5-A		7.5(3.7*2)/10		63			0.8	G1	11807601250	280
MA-PD-11-A		11(3.7+3)/15		64			1.2	G1	11807601690	496
MA-PD-15-A		15(3.7*4)/20		64			1.6	G1	150011801250	554
MA-PD-18.5-A		18.5(3.7*5)/25		65			2	G1.25	142010101510	808
MA-PD-22-A		22(3.7*6)/30		65			2.4	G1.5	142010101510	878
MA-PD-26-A		26(3.7*7)/35		65			2.8	G1.5	165015501950	1041
MA-PD-30-A		30(3.7*8)/40		68			3.2	G1.5	165015501950	1110
MA-PD-33-A		33(3.7*9)/45		68			3.6	G1.5	165015501950	1200
MA-PD-37-A		37(3.7*10)/50		68			4	G1.5	165015501950	1350
MA-PD-5.5-B		5.5/7.5		63			0.6	G1/2	680600960	151
MA-PD-11-B		11(5.5*2)/15		64			1.2	G1	11807601250	350
MA-PD-16.5-B		16.5(5.5*3)/22.5		64			1.8	G1	11807601690	556
MA-PD-22-B		22(5.5*4)/30		65			2.4	G1.25	150011801250	643
MA-PD-27.5-B		27.5(5.5*5)/37.5		65			3	G1.5	150011801690	785
MA-PD-33-B		33(5.5*6)/45		66			3.6	G1.5	150011801690	870
MA-PD-38.5-B		38.5(5.5*7)/52.5		68			4.2	G1.5	165015501500	1201
MA-PD-44-B		44(5.5*8)/60		68			4.8	G1.5	165015501500	1413
MA-PD-49.5-B		49.5(5.5*9)/67.5		68			5.4	G1.5	165015501950	1330
MA-PD-55-B		55(5.5*10)/75		68			6	G1.5	165015501950	1420

Note: Belt frequency machine(PD), A stands for 3.7Kw head, B stands for 5.5Kw head; The above models can use 10bar, the power is unchanged, and the flow rate is reduced by 15%;
